T-Slotted Framing Panels and Doors
Add panels to T-slotted framing to create machine guards and strip doors.
For technical drawings and 3-D models, click on a part number.
Acrylic panels are more scratch resistant than polycarbonate plastic for better clarity.
Polycarbonate panels are more impact resistant than acrylic plastic.
Opening | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lg., ft. | Wd., ft. | Color | Material | Thick. | Wire Dia. | Shape | Dia. | Lg. | Wd. | Each | |
Mesh | |||||||||||
| 2 | 2 | Black | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 000000 |
| 2 | 2 | Yellow | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 00000 |
| 4 | 2 | Black | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 00000 |
| 4 | 2 | Yellow | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 00000 |
| 4 | 4 | Black | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 00000 |
| 4 | 4 | Yellow | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 00000 |
| 8 | 4 | Black | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 000000 |
| 8 | 4 | Yellow | PVC Coated Steel | __ | 1/8" | Square | __ | 1" | 1" | 000000000 | 000000 |
Perforated | |||||||||||
| 2 | 2 | Silver | Anodized Aluminum | 1/8" | __ | Round | 3/8" | __ | __ | 000000000 | 00000 |
| 4 | 2 | Silver | Anodized Aluminum | 1/8" | __ | Round | 3/8" | __ | __ | 000000000 | 000000 |
| 4 | 4 | Silver | Anodized Aluminum | 1/8" | __ | Round | 3/8" | __ | __ | 000000000 | 000000 |
| 8 | 4 | Silver | Anodized Aluminum | 1/8" | __ | Round | 3/8" | __ | __ | 000000000 | 000000 |
Solid | |||||||||||
| 2 | 2 | Clear | Acrylic Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 00000 |
| 2 | 2 | Clear | Polycarbonate Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 00000 |
| 4 | 2 | Clear | Acrylic Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 00000 |
| 4 | 2 | Clear | Polycarbonate Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 00000 |
| 4 | 4 | Clear | Acrylic Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 000000 |
| 4 | 4 | Clear | Polycarbonate Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 000000 |
| 8 | 4 | Clear | Acrylic Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 000000 |
| 8 | 4 | Clear | Polycarbonate Plastic | 1/4" | __ | __ | __ | __ | __ | 000000000 | 000000 |
Screw-on panel hangers mount to framing with the included fasteners. To mount a panel, choose fasteners (not included) based on the thickness of your panel.
Extended panel hangers are wider than other panel hangers and have additional attachment points for a more secure connection.
For Rail Ht. | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | Color | Material | Mounting Fasteners Included | Each | |
For Solid Panels | |||||||||
Single-Plate Hangers | |||||||||
Standard | |||||||||
| 1" | 2" | 3" | 1 15/16" | 1" | Black | Anodized Aluminum | Yes | 00000000 | 000000 |
| 1 1/2" | 3" | 4 1/2" | 2 7/8" | 1 1/2" | Black | Anodized Aluminum | Yes | 00000000 | 00000 |
| 20mm | 40mm | __ | 1 9/16" | 13/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
| 25mm | 50mm | __ | 1 15/16" | 1" | Silver | Anodized Aluminum | Yes | 0000000 | 0000 |
| 30mm | 60mm | __ | 2 11/16" | 1 3/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
| 40mm | 80mm | 120mm | 3 1/16" | 1 9/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
| 45mm | 90mm | __ | 3 1/2" | 1 13/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
Extended | |||||||||
| 1" | 2" | 3" | 1 15/16" | 2" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 2 7/8" | 3" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 20mm | 40mm | __ | 1 9/16" | 1 9/16" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 25mm | 50mm | __ | 1 15/16" | 2" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
| 30mm | 60mm | __ | 2 5/16" | 2 3/8" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 40mm | 80mm | 120mm | 3" | 3 1/8" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 45mm | 90mm | __ | 3 7/16" | 3 9/16" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
For Mesh Panels | |||||||||
Single-Plate Hangers | |||||||||
Standard | |||||||||
| 1" | 2" | 3" | 1 15/16" | 1" | Black | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 2 7/8" | 1 1/2" | Black | Anodized Aluminum | Yes | 00000000 | 00000 |
| 20mm | 40mm | __ | 1 9/16" | 13/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
| 25mm | 50mm | __ | 1 15/16" | 1 1/4" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
| 30mm | 60mm | __ | 2 11/16" | 1 3/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
| 40mm | 80mm | 120mm | 3 1/16" | 1 9/16" | Silver | Anodized Aluminum | Yes | 00000000 | 0000 |
| 45mm | 90mm | __ | 3 1/2" | 1 13/16" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
Extended | |||||||||
| 1" | 2" | 3" | 1 15/16" | 2" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 2 7/8" | 3" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 25mm | 50mm | __ | 1 15/16" | 2" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
| 40mm | 80mm | 120mm | 3" | 3 1/8" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
Screw-on panel hangers mount to framing with the included fasteners. To mount a panel, choose fasteners (not included) based on the thickness of your panel.
Double-plate panel hangers attach panels on two sides of a rail.
Extended panel hangers are wider than other panel hangers and have additional attachment points for a more secure connection.
For Rail Ht. | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | Color | Material | Mounting Fasteners Included | Each | |
For Solid Panels | |||||||||
Double-Plate Hangers | |||||||||
Standard | |||||||||
| 1" | 2" | 3" | 3" | 1" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 4 1/2" | 1 1/2" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 25mm | 50mm | __ | 3" | 1" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
| 40mm | 80mm | 120mm | 4 3/4" | 1 9/16" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
Extended | |||||||||
| 1" | 2" | 3" | 3" | 2" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 4 1/2" | 3" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
For Mesh Panels | |||||||||
Double-Plate Hangers | |||||||||
Standard | |||||||||
| 1" | 2" | 3" | 3" | 1" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 4 1/2" | 1 1/2" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 25mm | 50mm | __ | 3" | 1 1/4" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
| 40mm | 80mm | 120mm | 4 3/4" | 1 9/16" | Silver | Anodized Aluminum | Yes | 0000000 | 00000 |
Screw-on panel hangers mount to framing with the included fasteners. To mount a panel, choose fasteners (not included) based on the thickness of your panel.
Dual-mount panel hangers hold a panel flush with a rail or overlapping the rail to cover the slot.
For Rail Ht. | For Solid Panels | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | Color | Material | Mounting Fasteners Included | Each | |
Dual-Mount Hangers | |||||||||
Standard | |||||||||
| 1" | 2" | 3" | 13/16" | 11/16" | Black | Powder-Coated Aluminum | Yes | 0000000 | 000000 |
| 1" | 2" | 3" | 13/16" | 3/4" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 1 1/4" | 7/8" | Black | Powder-Coated Aluminum | Yes | 0000000 | 00000 |
| 1 1/2" | 3" | 4 1/2" | 1 1/4" | 1" | Silver | Anodized Aluminum | Yes | 00000000 | 00000 |
| 25mm | 50mm | __ | 1" | 13/16" | Silver | Anodized Aluminum | Yes | 0000000 | 0000 |
| 40mm | 80mm | 120mm | 1 3/8" | 15/16" | Silver | Powder-Coated Aluminum | Yes | 0000000 | 0000 |
| 40mm | 80mm | 120mm | 1 3/8" | 15/16" | Black | Powder-Coated Aluminum | Yes | 0000000 | 0000 |
| 45mm | 90mm | __ | 1 9/16" | 1" | Silver | Powder-Coated Aluminum | Yes | 0000000 | 00000 |
| 45mm | 90mm | __ | 1 9/16" | 1" | Black | Powder-Coated Aluminum | Yes | 0000000 | 00000 |
Screw-on panel hangers mount to framing with the included fasteners.
Hangers for glass panels have rubber pads that clamp around the panel. They don’t require machining.
For Rail Ht. | For Solid Panels | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | Color | Material | Mounting Fasteners Included | Each | |
Hangers for Glass Panels | |||||||||
Standard | |||||||||
| 1 1/2" | 3" | 4 1/2" | 1 13/16" | 1" | Silver | Powder-Coated Zinc | Yes | 0000000 | 000000 |
| 25mm | 50mm | __ | 1 13/16" | 1" | Silver | Powder-Coated Zinc | Yes | 0000000 | 00000 |
| 40mm | 80mm | 120mm | 1 13/16" | 1" | Silver | Powder-Coated Zinc | Yes | 0000000 | 00000 |
Screw-on panel hangers mount to framing with the included fasteners.
Hangers for perpendicular panels can be used to create a shelf.
For Rail Ht. | For Solid Panels | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | Color | Material | Mounting Fasteners Included | Each | |
Hangers for Perpendicular Panels | |||||||||
Standard | |||||||||
| 1 1/2", 40mm | 3", 80mm | 4 1/2", 120mm | 2 1/4" | 1 3/16" | Silver | Aluminum Coated Zinc | Yes | 0000000 | 000000 |
Flush
with Rail
Snap-in panel hangers don’t require fasteners to attach to a rail. They are not as secure as screw-on hangers.
Hangers for solid panels mount panels flush to the rail. To mount a panel, choose fasteners (not included) based on the thickness of your panel. Hangers for two panels hold panels on either side of the hanger. Use self-tapping screws to secure panels to the hanger. These hangers are often used to reduce noise from machines or offer protection from large flying objects and liquid.
Hangers for mesh panels mount the panel in the rail.
For Rail Ht. | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | For Max. Wire Dia. | For Max. Panel Thick. | For Max. No. of Panels | Color | Material | Safety Properties | Each | |
For Solid Panels | ||||||||||||
| 1" | 2" | 3" | 1 3/16" | 1" | __ | __ | 1 | Silver | Anodized Aluminum | __ | 00000000 | 00000 |
| 1 1/2", 40mm | 3", 80mm | 4 1/2", 120mm | 1 13/16" | 1 1/2" | __ | __ | 1 | Silver | Anodized Aluminum | __ | 00000000 | 0000 |
| 40mm | 80mm | 120mm | 3ft. | 13/16" | __ | 11/16" | 2 | Silver | Anodized Aluminum | Static Control | 0000000 | 00000 |
| 40mm | 80mm | 120mm | 6ft. | 13/16" | __ | 11/16" | 2 | Silver | Anodized Aluminum | Static Control | 0000000 | 00000 |
For Mesh Panels | ||||||||||||
| 1 1/2", 40mm | 3", 80mm | 4 1/2", 120mm | 3/4" | 5/8" | 1/8" | __ | 1 | Black | Plastic | __ | 00000000 | 0000 |
Twist-on panel hangers twist into a T-slot and don't require fasteners. They are not as secure as screw-on hangers.
Clear hangers are less noticeable than others because they blend in with panels.
Push-in panel hangers fit a panel exactly in the rail slot, so it won’t rattle from vibration. Use scissors to cut them to size before pressing them into the rail. While they don’t require fasteners, they are not as secure as screw-on hangers.
Static control hangers prevent static discharge from building up, protecting sensitive electronic equipment.
For Rail Ht. | For Solid Panels | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | For T-Slot Wd. | Lg., ft. | For Min. Panel Thick. | For Max. Panel Thick. | Safety Properties | Color | Material | Each | |
| 1 1/2", 40mm | 3", 80mm | 4 1/2", 120mm | 0.32", 8mm | 6 1/2 | 5/32" | 7/32" | Static Control | Black | Plastic | 0000000 | 000000 |
| 20mm | 40mm | __ | 5mm | 6 1/2 | 1/16" | 3/32" | __ | Gray | Plastic | 0000000 | 0000 |
| 20mm | 40mm | __ | 5mm | 6 1/2 | 1/16" | 3/32" | Static Control | Black | Plastic | 0000000 | 0000 |
| 20mm | 40mm | __ | 5mm | 6 1/2 | 1/16" | 5/32" | __ | Black | Plastic | 0000000 | 0000 |
| 30mm | 60mm | __ | 8mm | 6 1/2 | 5/32" | 1/4" | __ | Black | Plastic | 0000000 | 0000 |
Lift-off panel hangers can be easily removed for access. To mount a panel, choose fasteners (not included) based on the thickness of your panel.
For Rail Ht. | For Solid Panels | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Lg. | Wd. | Color | Material | Mounting Fasteners Included | Each | |
| 1", 30mm | 2", 60mm | 3" | 1 9/16" | 15/16" | Black | Powder-Coated Zinc | Yes | 00000000 | 000000 |
Strip doors are sized to fit short openings and allow access while keeping dirt, dust, and debris out. They snap into the rail.
For Rail Ht. | Strips | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Double, Quad | Triple | Wd. | Ht. | No. of | Wd. | Thick. | Color | Material | Each | |
| 1" | 2" | 3" | 36" | 36" | 9 | 4" | 0.06" | Clear | PVC Plastic | 000000000 | 0000000 |
| 1" | 2" | 3" | 48" | 36" | 12 | 4" | 0.06" | Clear | PVC Plastic | 000000000 | 000000 |
| 1" | 2" | 3" | 48" | 48" | 12 | 4" | 0.06" | Clear | PVC Plastic | 000000000 | 000000 |
| 1" | 2" | 3" | 60" | 36" | 15 | 4" | 0.06" | Clear | PVC Plastic | 000000000 | 000000 |
| 1" | 2" | 3" | 60" | 60" | 15 | 4" | 0.06" | Clear | PVC Plastic | 000000000 | 000000 |
T-Slotted Framing Hinges
Use hinges to add doors, lids, and machine guards to T-slotted framing.
Rail-to-rail hinges provide smooth motion at the junction between two rails. Rail-to-panel hinges provide smooth motion at the junction between a rail and a panel.
For technical drawings and 3-D models, click on a part number.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | Lg. | Ht. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | |||||||
|---|---|---|---|---|---|---|---|
| 1" | Silver | Lacquer-Coated Aluminum | 2 1/16" | 1 7/8" | Yes | 000000000 | 000000 |
| 1" | Black | Anodized Aluminum | 2" | 2" | Yes | 000000000 | 00000 |
| 1 1/2" | Silver | Anodized Aluminum | 3" | 3" | Yes | 000000000 | 00000 |
| 1 1/2" | Silver | Lacquer-Coated Aluminum | 3 1/16" | 1 7/8" | Yes | 000000000 | 00000 |
| 1 1/2" | Black | Anodized Aluminum | 3" | 3" | Yes | 000000000 | 00000 |
| 20mm | Silver | Lacquer-Coated Aluminum | 1 1/2" | 1 3/16" | Yes | 00000000 | 00000 |
| 20mm | Black | Plastic | 1 1/4" | 3/4" | Yes | 0000000 | 0000 |
| 30mm | Silver | Lacquer-Coated Aluminum | 2 5/16" | 1 7/8" | Yes | 00000000 | 00000 |
| 30mm | Black | Plastic | 2 3/8" | 1 9/16" | Yes | 00000000 | 0000 |
| 40mm | Silver | Anodized Aluminum | 3" | 3" | Yes | 000000000 | 00000 |
| 40mm | Silver | Lacquer-Coated Aluminum | 3 1/16" | 1 7/8" | Yes | 00000000 | 00000 |
| 40mm | Black | Anodized Aluminum | 3" | 3" | Yes | 000000000 | 00000 |
| 45mm | Silver | Lacquer-Coated Aluminum | 3 7/16" | 1 7/8" | Yes | 00000000 | 00000 |
Hinges for three rails let you add a door to both sides of one rail.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | For Max. Panel Thick. | Lg. | Ht. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | ||||||||
|---|---|---|---|---|---|---|---|---|
| 20 mm | Black | Plastic | 1/4" | 1 7/16" | 1 11/16" | Yes | 00000000 | 00000 |
Reducer hinges join rails of different heights.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Reducer hinges join rails of different heights.
Hinges for three rails let you add a door to both sides of one rail.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Slotted-hole hinges give you some wiggle room when mounting these hinges to your rails, allowing you to customize the position of your rails.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | Lg. | Ht. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | |||||||
|---|---|---|---|---|---|---|---|
| 1 1/2", 40mm | Black | Painted Steel | 2 1/2" | 1 9/16" | Yes | 00000000 | 000000 |
| 1 1/2", 40mm | Black | Plastic | 2 9/16" | 1 9/16" | Yes | 00000000 | 00000 |
| 40mm | Black | Powder-Coated Zinc | 3 1/8" | 1 9/16" | Yes | 0000000 | 00000 |
| 45mm | Black | Powder-Coated Zinc | 3 1/8" | 1 9/16" | Yes | 00000000 | 00000 |
Friction hinges provide constant resistance through the full range of motion to hold lids, panels, and doors at any angle. Tighten or loosen the adjustment screw to change the resistance of the hinge.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Friction hinges provide constant resistance through the full range of motion to hold lids, panels, and doors at any angle. Tighten or loosen the adjustment screw to change the resistance of the hinge.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | For Max. Panel Thickness | Lg. | Ht. | Torque, in.-lbs. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 1" | Black | Plastic | 1/4" | 1 7/16" | 1 11/16" | 7 | Yes | 000000000 | 000000 |
| 1 1/2" | Black | Plastic | 1/4" | 2 1/4" | 2 1/2" | 35 | Yes | 000000000 | 00000 |
| 25mm | Black | Plastic | 1/4" | 1 11/16" | 1 7/16" | 7 | Yes | 00000000 | 00000 |
| 40mm | Black | Plastic | 1/4" | 2 1/4" | 2 1/2" | 35 | Yes | 00000000 | 00000 |
Hinges with bearings move smoothly as they open and close.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Bearing | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| For Rail Ht. | Color | Material | Material | Type | Lg. | Ht. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | |||||||||
| 30 mm | Silver | Aluminum | PTFE Plastic | Sleeve | 3 3/4" | 2 1/4" | Yes | 00000000 | 000000 |
| 40 mm | Silver | Aluminum | PTFE Plastic | Sleeve | 3 3/4" | 2 11/16" | Yes | 00000000 | 00000 |
| 45 mm | Silver | Aluminum | PTFE Plastic | Sleeve | 3 3/4" | 3 1/16" | Yes | 0000000 | 00000 |
Two-way hinges open doors and gates in both directions. A spring automatically pulls them closed. Use the included tension adjustment tool to change how quickly they close.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | Lg. | Ht. | Range of Motion | Closing Tension | Mounting Fasteners Included | Includes | Each | |
Nonremovable Pin—Reversible | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1 1/2", 40mm | Silver | 201 Stainless Steel | 5 1/2" | 4 1/16" | 350° | Adjustable | Yes | Tension Adjustment Tool | 0000000 | 000000 |
| 1 1/2", 40mm | Black | 201 Stainless Steel | 5 1/2" | 4 1/16" | 350° | Adjustable | Yes | Tension Adjustment Tool | 00000000 | 00000 |
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | Lg. | Ht. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | |||||||
|---|---|---|---|---|---|---|---|
| 1" | Silver | Anodized Aluminum | 1 13/16" | 2 5/16" | Yes | 000000000 | 000000 |
| 1" | Black | Anodized Aluminum | 1 3/4" | 2 5/16" | Yes | 000000000 | 00000 |
| 1 1/2" | Silver | Anodized Aluminum | 2 13/16" | 2 5/16" | Yes | 00000000 | 00000 |
| 1 1/2" | Black | Anodized Aluminum | 2 3/4" | 2 5/16" | Yes | 000000000 | 00000 |
Hinges with a lift-off pin have a permanently attached pin for quickly lifting the door off the hinge without removing the pin. To choose between right-side and left-side hinges, stand on the pull side of your door. Use a left-side hinge if the hinge will be on the left of your door. Use a right-side hinge if the hinge will be on the right of your door.
| For Rail Ht. | Color | Material | Lg. | Ht. | Mounting Fasteners Included | Each | |
Lift-Off Pin—Left Side | |||||||
|---|---|---|---|---|---|---|---|
| 1" | Silver | Anodized Aluminum | 2" | 2" | Yes | 000000000 | 000000 |
| 1 1/2", 40mm | Silver | Anodized Aluminum | 3" | 3" | Yes | 000000000 | 00000 |
Lift-Off Pin—Right Side | |||||||
| 1" | Silver | Anodized Aluminum | 2" | 2" | Yes | 000000000 | 00000 |
| 1 1/2", 40mm | Silver | Anodized Aluminum | 3" | 3" | Yes | 000000000 | 00000 |
Hinges with a lift-off pin have a permanently attached pin for quickly lifting the door off the hinge without removing the pin.
Hinges for three rails let you add a door to both sides of one rail.
| For Rail Ht. | Color | Material | Lg. | Ht. | Mounting Fasteners Included | Each | |
Lift-Off Pin—Reversible | |||||||
|---|---|---|---|---|---|---|---|
| 1 1/2" | Gray | Plastic | 3 15/16" | 1 1/4" | Yes | 00000000 | 000000 |
Lever lock position hinges can lock open at any angle up to 180°. Pull the lever up and turn it a quarter turn to make adjustments.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
| For Rail Ht. | Color | Material | Lg. | Ht. | Mounting Fasteners Included | Each | |
Nonremovable Pin—Reversible | |||||||
|---|---|---|---|---|---|---|---|
| 1" | Black | Nickel-Plated Aluminum | 2 3/8" | 1 7/8" | Yes | 000000000 | 000000 |
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Knuckle | 1 ft. Lg. | 3 ft. Lg. | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| For Rail Ht. | Color | Material | Ht. | Dia. | Lg. | Mounting Fasteners Included | Each | Each | ||
Nonremovable Pin—Reversible | ||||||||||
| 1" | Silver | Anodized Aluminum | 2" | 0.45" | 1" | Yes | 0000000 | 000000 | 0000000 | 000000 |
| 1 1/2" | Silver | Anodized Aluminum | 3" | 0.45" | 1" | Yes | 0000000 | 00000 | 0000000 | 00000 |
| 40mm | Silver | Anodized Aluminum | 3" | 0.45" | 1" | Yes | 0000000 | 00000 | 0000000 | 00000 |
Safety hinges have a switch that automatically shuts off power to machinery when an access door opens. If your door requires more than one hinge, only one needs to have a safety switch; use hinges without a safety switch for the rest. Make sure to mount the safety switch on the rail that won't be moving.
Hinges with a nonremovable pin are reversible and work on left- and right-side doors.
Safety Hinges | Hinges without Safety Switch | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| For Rail Ht. | Color | Material | Lg. | Ht. | Switching Current | Switching Voltage | Switch Location | Input Voltage | Environmental Rating | Mounting Fasteners Included | Each | Each | ||
Nonremovable Pin—Reversible | ||||||||||||||
Micro M12 Connection on Top | ||||||||||||||
| 1" | Black | Plastic | 2 3/8" | 4 5/16" | 2A | 24V AC/24V DC | Right Side | 24V AC/24V DC | IP67 | Yes | 00000000 | 0000000 | 00000000 | 000000 |
| 1 1/2", 40mm | Black | Plastic | 2 3/8" | 4 5/16" | 2A | 24V AC/24V DC | Right Side | 24V AC/24V DC | IP67 | Yes | 00000000 | 000000 | 00000000 | 00000 |
Micro M12 Connection on Bottom | ||||||||||||||
| 1" | Black | Plastic | 2 3/8" | 4 5/16" | 2A | 24V AC/24V DC | Right Side | 24V AC/24V DC | IP67 | Yes | 00000000 | 000000 | 00000000 | 00000 |
T-Slotted Framing Storage Components
Stay organized with these storage components that work with T-slotted framing.
For technical drawings and 3-D models, click on a part number.
Panels have continuous 40 mm slots to make it easy to organize and move around tools, bin box holders, and other components on the panel. You can add accessories to either side of the panel. They're static control, so they prevent electrostatic discharge from building up, protecting sensitive electronic equipment.
Mounting brackets for T-slotted panels mount panels flush with a rail. You can use them to mount a panel to create a wall or a tabletop. They’re static control, so they prevent electrostatic discharge from building up, protecting sensitive electronic equipment.
For Rail | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Profile | Ht. | Lg. | Wd. | Ht. | Material | Color | Mounting Fasteners Included | Each | |
Static Control Brackets | |||||||||
| Single | 40mm | 1 3/8" | 1 1/16" | 7/8" | Zinc-Plated Steel | Silver | Yes | 000000000 | 000000 |
Connectors for T-slotted panels let you stack T-slotted panels on top of each other to add height.
| Lg. | Wd. | Ht. | Material | Color | Each | |
| 13/16" | 5/16" | 5/8" | Plastic | Gray | 000000000 | 00000 |
End caps for T-slotted panels cover cut ends of T-slotted panels that aren’t framed with other material.
| Lg. | Wd. | Ht. | Material | Color | Each | |
| 7 7/8" | 9/16" | 3/16" | Plastic | Gray | 000000000 | 00000 |
