Brass Push-to-Connect Fittings for Copper Tubing
- Tubing: Use with K, M, L copper, polyethylene plastic
Connect these fittings to copper tubing with a push—no heat, solder, or flux required. They have an internal gripping ring and O-ring that hold the fitting secure. They also come with a tube support if you want to use them with polyethylene plastic (PEX) tubing. They are also known as instant fittings. Fittings are brass for good corrosion resistance. They are compatible with SharkBite® fittings. To adhere to safety standards for drinking water systems, use fittings that meet NSF/ANSI 61.
For technical drawings and 3-D models, click on a part number.
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Pipe Size | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
NPT Threads | ||||||||
---|---|---|---|---|---|---|---|---|
1/4 | 3/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/8 | 1/2" | 3/8 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
3/8 | 1/2" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1/2 | 5/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1/2 | 5/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
3/4 | 7/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 0000 |
3/4 | 7/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
3/4 | 7/8" | 1 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 | 1 1/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 | 1 1/8" | 1 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 1/4 | 1 3/8" | 1 1/4 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | 1 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
2 | 2 1/8" | 2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
- For Use With:
1 1/4 Copper Tube Size: Air, Drinking Water, Water
All Other Copper Tube Size: Air, Drinking Water - Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Pipe Size | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
NPT Threads | ||||||||
---|---|---|---|---|---|---|---|---|
1/4 | 3/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/8 | 1/2" | 3/8 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
3/8 | 1/2" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1/2 | 5/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1/2 | 5/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
3/4 | 7/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 0000 |
3/4 | 7/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1 | 1 1/8" | 1 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 1/4 | 1 3/8" | 1 1/4 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | 1 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
2 | 2 1/8" | 2 | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
- For Use With: Air, Water, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Use adapters for polybutylene tubing to transition from old water supply plumbing to copper or polyethylene tubing.
- For Use With: Water, Drinking Water
- Temperature Range: 35° to 200° F
- Specifications Met: NSF/ANSI 61
Connect copper tubing to PVC pipe. These adapters are also known as transition couplings. To remove the adapter from your PVC pipe, you'll need a release clip with depth gauge (sold separately).
Tube Connection | Pipe Connection | ||||||||
---|---|---|---|---|---|---|---|---|---|
Copper Tube Size | For Tube OD | For Pipe Material | Pipe Size | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/2 | 5/8" | PVC Plastic | 1/2 | Brass | Plastic | Tan, White | 200 psi @ 72° F | 00000000 | 000000 |
3/4 | 7/8" | PVC Plastic | 3/4 | Brass | Plastic | Tan, White | 200 psi @ 72° F | 00000000 | 00000 |
1 | 1 1/8" | PVC Plastic | 1 | Brass | Plastic | Tan, White | 200 psi @ 72° F | 00000000 | 00000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Fittings with tube stem insert into the tube end of another fitting in place of a length of tubing.
Tube Stem Connection | Tube Connection | ||||||||
---|---|---|---|---|---|---|---|---|---|
Copper Tube Size | Tube Stem OD | Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/2 | 5/8" | 3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/4 | 7/8" | 3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 | 1 1/8" | 1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Fittings with tube stem insert into the tube end of another fitting in place of a length of tubing.
Copper Tube Size | Tube Stem OD | Pipe Size | Material | Max. Pressure | Each | |
NPT Threads | ||||||
---|---|---|---|---|---|---|
1 | 1 1/8" | 1 | Brass | 200 psi @ 72° F | 00000000 | 000000 |
- For Use With: Air, Water
- Temperature Range: 32° to 200° F
Connect copper tubing to CPVC pipe. These adapters are also known as transition couplings. Fittings with tube stem insert into the tube end of another fitting in place of a length of tubing.
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/4 | 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 1/4 | 1 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
2 | 2 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
- For Use With: Air, Drinking Water, Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Fittings with offset configuration are smooth inside the longer end, giving extra clearance so they can slide freely over the end of a tube to repair a leak. They’re also known as slip couplings and repair couplings.
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Tube Connection (A) | Tube Connection (B) | ||||||||
---|---|---|---|---|---|---|---|---|---|
Copper Tube Size | For Tube OD | Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/2 | 5/8" | 3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
3/4 | 7/8" | 1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
1 | 1 1/8" | 3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 1/2 | 1 5/8" | 1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Pipe Size | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
NPT Threads | ||||||||
---|---|---|---|---|---|---|---|---|
1/4 | 3/8" | 3/8 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 000000 |
3/8 | 1/2" | 3/8 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1/2 | 5/8" | 3/8 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 0000 |
1/2 | 5/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 0000 |
3/4 | 7/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Pipe Size | Material | Release Ring Material | Release Ring Color | Max. Pressure | Mounting Hole Dia. | Each | |
NPT Threads | |||||||||
---|---|---|---|---|---|---|---|---|---|
3/8 | 1/2" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 13/64" | 00000000 | 00000 |
1/2 | 5/8" | 1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 13/64" | 00000000 | 0000 |
3/4 | 7/8" | 3/4 | Brass | Plastic | Black | 200 psi @ 72° F | 13/64" | 00000000 | 00000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/4 | 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 |
3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 1/4 | 1 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
2 | 2 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
- For Use With: Air, Drinking Water, Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/2 | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 000000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Tube Connection (A) | Tube Connection (B) | ||||||||
---|---|---|---|---|---|---|---|---|---|
Copper Tube Size | For Tube OD | Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/2 | 5/8" | 3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/4 | 7/8" | 1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 | 1 1/8" | 3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/4 | 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 |
1 1/4 | 1 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 000000 |
2 | 2 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 000000 |
- For Use With:
3/8-1 Copper Tube Size for Tube Connection (A): Air, Drinking Water
1 1/4-2 Copper Tube Size for Tube Connection (A): Air, Drinking Water, Water - Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Inline tees are also known as branch tees.
Tube Connection (A) | Tube Connection (B) | ||||||||
---|---|---|---|---|---|---|---|---|---|
Copper Tube Size | For Tube OD | Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | |
1/2 | 5/8" | 1/4 | 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 000000 |
1/2 | 5/8" | 3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
3/4 | 7/8" | 1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 | 1 1/8" | 3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/4 | 1 3/8" | 3/4 | __ | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/4 | 1 3/8" | 1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | 3/4 | __ | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
1 1/2 | 1 5/8" | 1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 |
2 | 2 1/8" | 1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 000000 |
- For Use With: Air, Drinking Water, Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Inline tees are also known as branch tees.
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Right-angle tees are also known as run tees.
- For Use With: Air, Drinking Water
- Temperature Range: 32° to 200° F
- Specifications Met: NSF/ANSI 61
Caps with drain let you clear your line without disconnecting your fittings.
Standard Caps | Caps With Drain | ||||||||
---|---|---|---|---|---|---|---|---|---|
Copper Tube Size | For Tube OD | Material | Release Ring Material | Release Ring Color | Max. Pressure | Each | Each | ||
1/4 | 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 | 000000 | 00 |
3/8 | 1/2" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 | 000000 | 00 |
1/2 | 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 | 00000000 | 00000 |
3/4 | 7/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 0000 | 00000000 | 00000 |
1 | 1 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 | 000000 | 00 |
1 1/4 | 1 3/8" | Brass | Plastic | Black | 200 psi @ 72° F | 00000000 | 00000 | 000000 | 00 |
1 1/2 | 1 5/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 | 000000 | 00 |
2 | 2 1/8" | Brass | Plastic | Black | 200 psi @ 72° F | 0000000 | 00000 | 000000 | 00 |
A release clip or release wrench is required to disconnect the fitting from the tubing.
Use release clips with a depth gauge to mark how far you need to insert your PVC pipe into its fitting to ensure a watertight connection.
For Copper Tube Size | For Tube OD | For Pipe Size | For Pipe Material | Features | Each | |
For Pipes | ||||||
---|---|---|---|---|---|---|
__ | __ | 1/2 | CPVC Plastic | __ | 00000000 | 00000 |
__ | __ | 1/2 | PVC Plastic | Depth Gauge | 00000000 | 0000 |
__ | __ | 3/4 | CPVC Plastic | __ | 00000000 | 0000 |
__ | __ | 3/4 | PVC Plastic | Depth Gauge | 00000000 | 0000 |
__ | __ | 1 | CPVC Plastic | __ | 00000000 | 0000 |
__ | __ | 1 | PVC Plastic | Depth Gauge | 00000000 | 0000 |
For Tubes | ||||||
3/8 | 1/2" | __ | __ | __ | 0000000 | 0000 |
1/2 | 5/8" | __ | __ | __ | 0000000 | 0000 |
3/4 | 7/8" | __ | __ | __ | 0000000 | 000 |
1 | 1 1/8" | __ | __ | __ | 0000000 | 0000 |
A release clip or release wrench is required to disconnect the fitting from the tubing.
For Copper Tube Size | For Tube OD | Each | |
1 1/4, 1 1/2, 2 | 1 3/8", 1 5/8", 2 1/8" | 0000000 | 000000 |
Use the chamfering and deburring depth gauge tool (sold separately) to deburr tubing before inserting it into the fitting.
For Copper Tube Size | For Tube OD | Each | |
3/8, 1/2, 3/4, 1 | 1/2", 5/8", 7/8", 1 1/8" | 00000000 | 000000 |
