Wrench-Driven Rivet Nut Tools
Use these tools to install most styles of rivet nuts. A wrench and ratchet are required to hold the tool and tighten the nut.
For technical drawings and 3-D models, click on a part number.
| For Thread Size | For Wrench Size | For Ratchet Size | For Rivet Nut Body Type | For Rivet Nut Material | Each | |
| 4-40 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 000000 |
| 6-32 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 8-32 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 10-24, 10-32 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 12-24 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 1/4"-20, 1/4"-28 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 5/16"-18, 5/16"-24 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 3/8"-16, 3/8"-24 | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 1/2"-13 | 7/8" | 7/8" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| 1/2"-20 | 7/8" | 7/8" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M3 × 0.5 mm | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M4 × 0.7 mm | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M5 × 0.8 mm | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M6 × 1 mm | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M8 × 1.25 mm | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M10 × 1.5 mm | 7/8" | 11/16" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
| M12 × 1.75 mm | 7/8" | 7/8" | Smooth, Ribbed, Hex, Bulbed, Sleeve | 18-8 Stainless Steel, Aluminum, Steel, Titanium | 000000000 | 00000 |
Light Duty Plier-Style Rivet Nut Tools
Install screw-to-install rivet nuts and rivet nuts for plastic and composites. Thread the rivet nut onto the pull rod (required, sold separately), insert the nut into the hole, and squeeze the handles to secure the nut. Friction wrenches designed to hold the nut head during installation are also available and sold separately.
Rivet Nut Tools | Friction Wrenches | ||||
|---|---|---|---|---|---|
For Steel Rivet Nut Thread Size | For Rivet Nut Body Type | Each | Each | ||
| 6-32, 10-24, 1/4"-20, M4, M5, M6 | Bulbed | 000000000 | 000000 | 000000000 | 00000 |
| Required Pull Rods for ¼"-20 Thread | 000000000 | Each | 0000000 |
| Required Pull Rods for M6 Thread | 000000000 | Each | 00000 |
| Required Pull Rods for 6-32 Thread | 000000000 | Each | 000000 |
| Required Pull Rods for M5 Thread | 000000000 | Each | 000000 |
| Required Pull Rods for 10-24 Thread | 000000000 | Each | 00000 |
| Required Pull Rods for M4 Thread | 000000000 | Each | 00000 |
Hydraulic/Air-Powered Rivet Nut Tools
Quickly install all styles of rivet nuts at 1.5-second intervals. The tool includes nosepiece assemblies to install M4, M5, M6, and M8 rivet nuts (additional sizes sold separately). To use, thread the nut onto the included mandrel and press the trigger to spin the nut onto the tool. Place the nut into the material and press the trigger to install the nut. Press the trigger one more time to spin the mandrel off.
Tools
Body | Air Connection | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| For Thread Size | For Rivet Nut Body Type | For Rivet Nut Material | Dia. | Wd. | Head Lg. | Overall Ht. | Max. Stroke Lg. | Pulling Force | Operating Pressure, psi | Pipe Size | Thread Type | Weight, lbs. | Each | |
| 4-40, 8-32, 10-24, 10-32, 1/4"-20, 1/4"-28, 5/16"-18, 5/16"-24, 3/8"-16, 3/8"-24, M4, M5, M6, M8, M10 | Smooth, Ribbed, Hex, Bulbed, Sleeve, Stud | Aluminum, Steel | 3 3/4" | 1 1/16" | 9 5/8" | 10 3/4" | 0.275" | 3,960 lbs | 75 to 100 | 1/4 | NPT | 3 1/2 | 000000000 | 000000000 |
Additional Nosepiece Assemblies
| For Thread Size | Each | |
| 4-40 | 000000000 | 000000 |
| 8-32 | 000000000 | 000000 |
| 10-24 | 000000000 | 000000 |
| 10-32 | 000000000 | 000000 |
| 1/4"-20 | 000000000 | 000000 |
| 1/4"-28 | 000000000 | 000000 |
| 5/16"-18 | 000000000 | 000000 |
| 5/16"-24 | 000000000 | 000000 |
| 3/8"-16 | 000000000 | 000000 |
| 3/8"-24 | 000000000 | 000000 |
| M4 × 0.7 mm | 000000000 | 000000 |
| M5 × 0.8 mm | 000000000 | 000000 |
| M6 × 1 mm | 000000000 | 000000 |
| M8 × 1.25 mm | 000000000 | 000000 |
| M10 × 1.5 mm | 000000000 | 000000 |
Maintenance Kits
| Includes | Each | |
| Hex Key Wrench, Pin-Removal Punch, Spanner Wrench | 000000000 | 000000 |
Air-Powered Rivet Nut Tools
Smaller and lighter than cordless and hydraulic rivet nut tools, use these to install thin-walled bulbed, ribbed, sleeve, and smooth rivet nuts. To use, thread the nut onto the included mandrel and press the trigger to spin the nut onto the tool. Place the nut into the material and press the trigger to install the nut. Press the trigger one more time to spin the mandrel off.
Tools
Air Connection | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| For Thread Size | For Rivet Nut Body Type | For Rivet Nut Material | Head Lg. | Overall Ht. | Operating Pressure, psi | Pipe Size | Thread Type | Weight, lbs. | Includes | Each | |
| 4-40 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 35 to 45 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 0000000 |
| 6-32 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 8-32 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 10-24 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 10-32 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 1/4"-20 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 1/4"-28 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 5/16"-18 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 90 to 110 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 5/16"-24 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 90 to 110 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 3/8"-16 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 90 to 110 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 3/8"-24 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 90 to 110 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| 1/2"-13 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 7 1/4" | 6" | 90 to 110 | 1/4 | NPT | 4 | Mandrel, Nosepiece | 000000000 | 00000000 |
| 1/2"-20 | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 7 1/4" | 6" | 90 to 110 | 1/4 | NPT | 4 | Mandrel, Nosepiece | 000000000 | 00000000 |
| M3 × 0.5 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 35 to 45 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| M4 × 0.7 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 35 to 45 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| M5 × 0.8 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| M6 × 1 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 70 to 80 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| M8 × 1.25 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 90 to 110 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| M10 × 1.5 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 6" | 6" | 90 to 110 | 1/4 | NPT | 3 | Mandrel, Nosepiece | 000000000 | 000000 |
| M12 × 1.75 mm | Bulbed, Ribbed, Sleeve, Smooth | Aluminum, Steel | 7 1/4" | 6" | 90 to 110 | 1/4 | NPT | 4 | Mandrel, Nosepiece | 000000000 | 00000000 |
Additional Mandrels
| For Thread Size | Each | |
| 4-40 | 000000000 | 00000 |
| 6-32 | 000000000 | 000 |
| 8-32 | 000000000 | 000 |
| 10-24 | 000000000 | 0000 |
| 10-32 | 000000000 | 0000 |
| 1/4"-20 | 000000000 | 0000 |
| 1/4"-28 | 000000000 | 0000 |
| 5/16"-18 | 000000000 | 0000 |
| 5/16"-24 | 000000000 | 0000 |
| 3/8"-16 | 000000000 | 0000 |
| 3/8"-24 | 000000000 | 0000 |
| 1/2"-13 | 000000000 | 0000 |
| 1/2"-20 | 000000000 | 0000 |
| M3 × 0.5 mm | 000000000 | 0000 |
| M4 × 0.7 mm | 000000000 | 0000 |
| M5 × 0.8 mm | 000000000 | 0000 |
| M6 × 1 mm | 000000000 | 0000 |
| M8 × 1.25 mm | 000000000 | 0000 |
| M10 × 1.5 mm | 000000000 | 0000 |
| M12 × 1.75 mm | 000000000 | 0000 |
Additional Nosepiece Assemblies
| For Thread Size | Includes | Each | |
| 4-40 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 0000000 |
| 6-32 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 8-32 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 10-24 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 10-32 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 1/4"-20 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 1/4"-28 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 5/16"-18 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 5/16"-24 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 3/8"-16 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 3/8"-24 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 1/2"-13 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| 1/2"-20 | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M3 × 0.5 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M4 × 0.7 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M5 × 0.8 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M6 × 1 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M8 × 1.25 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M10 × 1.5 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
| M12 × 1.75 mm | Bearing Set, Hex Drive, Mandrel, Nose Cone | 000000000 | 000000 |
Tools for Blind Rivets and Rivet Nuts
This tool has changeable nosepieces, anvils, and pull-up studs for installing rivets and rivet nuts. A self-contained hydraulic system delivers additional force to make installation easier. Choose the attachment that matches your rivet's diameter or nut thread size. To install a rivet, insert the mandrel into the nosepiece of the tool. Place the rivet in the material and squeeze the handles. The tool pulls the mandrel through the rivet's body, creating a secure hold on both sides of the material, and breaks off the excess mandrel.
Pull-up studs and driving anvils for 6-32 to 3/8"-16 and M3 to M10 rivet nuts are sold separately.
For technical drawings and 3-D models, click on a part number.
Tool
Nose | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Dia. | Lg. | Lg. | Ht. | For Rivet Nut Thread Size | For Rivet Nut Body Type | For Rivet Nut Material | Hydraulic Oil Included | Includes | Each | |
| 1 1/16" | 2 1/4" | 9 1/2" | 6 3/8" | 1/4"-20, 1/4"-28, 10-24, 10-32, 3/8"-16, 5/16"-18, 6-32, 8-32, M10, M3, M4, M5, M6, M8 | Bulbed, Sleeve, Smooth, Hex, Ribbed | Aluminum, Steel | Yes | Five nosepieces (3/32", 1/8", 5/32", 3/16", and 1/4") Two anvils (10-24 and 1/4"-20) Two pull-up studs (10-24 and 1/4"-20) | 0000000 | 0000000 |
Optional Steel Pull-Up Studs and Driving Anvils
| For Rivet Nut Thread Size | Lg. | Each | |
| 6-32 | 1 9/16" | 00000000 | 000000 |
| 8-32 | 1 1/4" | 00000000 | 00000 |
| 10-24 | 1 1/2" | 00000000 | 00000 |
| 10-32 | 1 1/2" | 00000000 | 00000 |
| 1/4"-20 | 1 13/16" | 00000000 | 00000 |
| 1/4"-28 | 1 1/2" | 00000000 | 00000 |
| 5/16"-18 | 2 1/8" | 00000000 | 00000 |
| 3/8"-16 | 2 1/8" | 0000000 | 00000 |
| M3 | 1 1/2" | 0000000 | 00000 |
| M4 | 1 7/16" | 00000000 | 00000 |
| M5 | 1 3/8" | 00000000 | 00000 |
| M6 | 1 13/16" | 00000000 | 00000 |
| M8 | 2" | 00000000 | 00000 |
| M10 | 1 7/16" | 00000000 | 00000 |
