Compare material, finish, length class, and decimal size equivalents.
Drill Bits
These jobbers'-length bits have the rigidity and length required for most applications.
Black-oxide and black-and-gold-oxide drill bits produce less friction than uncoated drill bits.
Titanium-nitride (TiN) coated drill bits last longer and can drill at higher speeds than uncoated and oxide-coated drill bits.
For technical drawings and 3-D models, click on a part number.
Shank | Each | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Overall Lg. | Max. Drilling Dp. | Type | Size | Point Style | For Use On | Each | |
Inch | |||||||||
Black-Oxide High-Speed Steel | |||||||||
39/64" | 0.6094" | 7 1/8" | 4.27" | Round | 39/64" | Standard | Steel, Iron, Stainless Steel | 0000000 | 000000 |
Titanium-Nitride (TiN) Coated High-Speed Steel | |||||||||
| 39/64" | 0.6094" | 7 1/8" | 4.27" | Round | 39/64" | Standard | Steel, Hardened Steel, Tool Steel, Iron, Stainless Steel, Nickel, Aluminum, Brass, Bronze, Plastic | 0000000 | 00000 |
Uncoated High-Speed Steel | |||||||||
| 39/64" | 0.6094" | 7 1/8" | 4.27" | Round | 39/64" | Standard | Steel, Iron, Aluminum, Brass, Bronze, Plastic | 0000000 | 00000 |
Short-Length Drill Bits
Also known as screw-machine and stub-length bits, these provide maximum rigidity for drilling straighter holes than jobbers'- and maintenance-length drill bits.
For technical drawings and 3-D models, click on a part number.
Shank | Each | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Overall Lg. | Max. Drilling Dp. | Type | Size | Point Style | Specifications Met | For Use On | Each | |
Inch | ||||||||||
Uncoated High-Speed Steel | ||||||||||
| 39/64" | 0.6094" | 4 1/4" | 1.83" | Round | 39/64" | Standard | ASME B94.11M | Steel, Iron, Stainless Steel | 00000000 | 000000 |
Extended-Length Drill Bits
Access hard-to-reach spots and drill deep holes.
Black-oxide drill bits produce less friction than uncoated drill bits.
For technical drawings and 3-D models, click on a part number.
Cobalt Steel Drill Bits
These jobbers'-length bits have the rigidity and length required for most applications. Made of cobalt steel, which has better heat and wear resistance than high-speed steel, they can run up to 25% faster and have a longer tool life.
Titanium-nitride (TiN) coated drill bits last longer and can drill at higher speeds than uncoated drill bits.
Drill bits with a split point keep centered without a pilot hole.
For technical drawings and 3-D models, click on a part number.
Shank | Each | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Overall Lg. | Max. Drilling Dp. | Type | Size | Point Style | Specifications Met | For Use On | Each | |
Inch | ||||||||||
Uncoated Cobalt Steel | ||||||||||
| 39/64" | 0.6094" | 7 1/8" | 4.2" | Round | 39/64" | Split | NAS907 Type J | Steel, Hardened Steel, Tool Steel, Iron, Stainless Steel, Nickel | 0000000 | 000000 |
Titanium-Nitride (TiN) Coated Cobalt Steel | ||||||||||
| 39/64" | 0.6094" | 7 1/8" | 5.19" | Round | 39/64" | Split | NAS907 Type J | Steel, Hardened Steel, Iron, Stainless Steel, Nickel, Titanium, Fiberglass | 000000000 | 00000 |
Extended-Length Carbide-Tipped Drill Bits
Access hard-to-reach spots and drill deep holes. More wear resistant than cobalt steel and high-speed steel, these carbide-tipped bits maintain a sharper, harder edge at high temperatures for excellent performance on abrasive material, such as plastic. Because they aren’t as brittle as solid carbide bits, they can be used in less rigid setups, such as a hand-held drill.
For technical drawings and 3-D models, click on a part number.
Shank | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Overall Lg. | Max. Drilling Dp. | Type | Size | Point Style | For Use On | Each | |
Inch | |||||||||
Uncoated Carbide-Tipped Steel | |||||||||
| 39/64" | 0.6094" | 8 3/4" | 3.96" | Round | 39/64" | Standard | Steel, Iron, Titanium, Aluminum, Brass, Bronze, Plastic | 00000000 | 000000 |
1/2" Diameter Reduced-Shank Drill Bits
The shank has a smaller diameter than the tip, allowing you to drill large holes with machines that have small-capacity chucks. Also known as Silver and Deming bits, they have a 1/2” diameter shank.
Drill bits with flats on shank have three flat sides to prevent the bit from slipping in the drill chuck.
Drill bits with a split point keep centered without a pilot hole.
For technical drawings and 3-D models, click on a part number.
Shank | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Overall Lg. | Max. Drilling Dp. | Type | Size | For Use On | Point Style | Each | |
Drill Bits | |||||||||
Inch | |||||||||
Black-Oxide High-Speed Steel | |||||||||
| 39/64" | 0.6094" | 6" | 2.1" | Reduced Round | 1/2" | Steel, Iron, Stainless Steel | Standard | 0000000 | 000000 |
Drill Bits with Flats on Shank | |||||||||
Inch | |||||||||
Black-Oxide High-Speed Steel | |||||||||
| 39/64" | 0.6094" | 6" | 2.1" | Reduced Round | 1/2" | Steel, Iron, Stainless Steel | Split | 0000000 | 00000 |
Extended-Length 1/2" Diameter Reduced-Shank Drill Bits
Access hard-to-reach spots and drill deep holes. The shank has a smaller diameter than the tip, allowing you to drill large holes with machines that have small-capacity chucks.
For technical drawings and 3-D models, click on a part number.
Shank | ||||||||
|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Type | Size | Point Style | For Use On | Max. Drilling Dp. | Each | |
12" Overall Lg. | ||||||||
Inch | ||||||||
Black-Oxide High-Speed Steel | ||||||||
| 39/64" | 0.6094" | Reduced Round | 1/2" | Standard | Steel, Iron, Stainless Steel | 9" | 0000000 | 000000 |
18" Overall Lg. | ||||||||
Inch | ||||||||
Black-Oxide High-Speed Steel | ||||||||
| 39/64" | 0.6094" | Reduced Round | 1/2" | Standard | Steel, Iron, Stainless Steel | 12" | 0000000 | 000000 |
Cobalt Steel 1/2" Diameter Reduced-Shank Drill Bits
With better heat and wear resistance than high-speed steel, these cobalt steel bits can run up to 25% faster and have a longer tool life. The shank has a smaller diameter than the tip, allowing you to drill large holes with machines that have small-capacity chucks. A split point keeps the bit centered without a pilot hole. Also known as Silver and Deming bits, they have a 1/2” diameter shank.
For technical drawings and 3-D models, click on a part number.
Shank | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | Overall Lg. | Max. Drilling Dp. | Type | Size | Point Style | For Use On | Each | |
Inch | |||||||||
Uncoated Cobalt Steel | |||||||||
| 39/64" | 0.6094" | 6" | 2.1" | Reduced Round | 1/2" | Split | Steel, Hardened Steel, Tool Steel, Iron, Stainless Steel, Nickel | 0000000 | 000000 |
High-Speed Steel Morse Taper-Shank Drill Bits
Install the Morse taper shank directly into the tapered spindle on machines such as drill presses and lathes.
For technical drawings and 3-D models, click on a part number.
Morse Taper | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Drill Bit Size | Decimal Size Equivalent | No. | Dia. | Overall Lg. | Max. Drilling Dp. | Shank Type | Point Style | For Use On | Each | |
Inch | ||||||||||
Black-Oxide High-Speed Steel | ||||||||||
| 39/64" | 0.6094" | 2 | 0.7" | 8 3/4" | 3.96" | Morse Taper | Standard | Steel, Iron, Stainless Steel | 00000000 | 000000 |
