Mitutoyo Electronic Height Gauges
Use the hand wheel to adjust height up and down the column, and set the attached scriber at a specific height for repeat marking. These gauges have zero-position memory, also known as absolute (ABS) positioning, which retains the measuring position when the gauge is turned off. A zero-set button lets you start measuring at any point. SPC data output allows for connection to a computer or data processor.
USB data cable (sold separately) connects the gauge directly to your PC.
10-pin data cables (sold separately) connect the gauge to a Mitutoyo miniprocessor or multiplexer.
Wireless data transmitter and receiver (sold separately) allow you to transmit measurement data from the gauge to your PC without being tethered by a cable.
Measuring Range | Accuracy | Measuring Increments | Base | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Metric | Inch | Metric | Inch | Metric | Column Material | Wd. | Lg. | Batteries Included | Manufacturer Model Number | Each | |
| 0"-12" | 0 mm-300 mm | ±0.0015" | ±0.040 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 7/16" | 6 5/16" | Yes | 570-412 | 0000000 | 0000000 |
| 0"-12" | 0 mm-300 mm | ±0.001" | ±0.025 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 3 9/16" | 5 5/16" | Yes | 192-630-10 | 0000000 | 00000000 |
| 0"-18" | 0 mm-450 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 3/4" | 7 1/8" | Yes | 192-631-10 | 0000000 | 00000000 |
| 0"-18" | 0 mm-450 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 3/4" | 7 1/8" | Yes | 570-413 | 0000000 | 00000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 3/4" | 7 1/8" | Yes | 192-632-10 | 0000000 | 00000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 5 5/8" | 7 1/8" | Yes | 570-414 | 0000000 | 00000000 |
Mitutoyo Electronic Height Gauges with Calibration Certificate
These gauges come with a calibration certificate traceable to NIST that states they've passed a test for accuracy. Use the hand wheel to adjust height up and down the column, and set the attached scriber at a specific height for repeat marking. Each gauge has zero-position memory, also known as absolute (ABS) positioning, which retains the measuring position when the gauge is turned off. A zero-set button lets you start measuring at any point. SPC data output allows for connection to a computer or data processor.
USB data cable (sold separately) connects the gauge directly to your PC.
10-pin data cables (sold separately) connect the gauge to a Mitutoyo miniprocessor or multiplexer.
Wireless data transmitter and receiver (sold separately) allow you to transmit measurement data from the gauge to your PC without being tethered by a cable.
Measuring Range | Accuracy | Measuring Increments | Base | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Metric | Inch | Metric | Inch | Metric | Column Material | Wd. | Lg. | Batteries Included | Manufacturer Model Number | Each | |
| 0"-12" | 0 mm-300 mm | ±0.0015" | ±0.040 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 7/16" | 6 5/16" | Yes | 570-412 | 0000000 | 0000000 |
| 0"-12" | 0 mm-300 mm | ±0.001" | ±0.025 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 3 9/16" | 5 5/16" | Yes | 192-630-10 | 0000000 | 00000000 |
| 0"-18" | 0 mm-450 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 3/4" | 7 1/8" | Yes | 192-631-10 | 0000000 | 00000000 |
| 0"-18" | 0 mm-450 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 3/4" | 7 1/8" | Yes | 570-413 | 0000000 | 00000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 4 3/4" | 7 1/8" | Yes | 192-632-10 | 0000000 | 00000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | Chrome-Plated Steel | 5 5/8" | 7 1/8" | Yes | 570-414 | 0000000 | 00000000 |
Starrett Electronic Height Gauges
Take height measurements and set the attached scriber at a specific height for repeat marking. These gauges have zero-position memory, also known as absolute (ABS) positioning, which retains the measuring position when the gauge is turned off. A zero-set button lets you start measuring at any point.
Measuring Range | Accuracy | Measuring Increments | Base | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Metric | Inch | Metric | Inch | Metric | Scale Measuring Increments | Column Material | Wd. | Lg. | Batteries Included | Manufacturer Model Number | Each | |
| 0"-12" | 0 mm-300 mm | ±0.0015" | ±0.040 mm | 0.0005" | 0.01 mm | 0.1" | Steel | 4" | 6" | Yes | 3754-12/300 | 00000000 | 0000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | 0.1" | Steel | 4 3/4" | 7 3/4" | Yes | 3754-24/600 | 00000000 | 00000000 |
| Replacement Battery (1/Pkg.) | 0000000 | Pkg. | 00000 |
Starrett Electronic Height Gauges with Calibration Certificate
These gauges come with a calibration certificate traceable to NIST that states they've passed a test for accuracy. They have a scriber that can be set at a specific height for repeat marking. All have zero-position memory, also known as absolute (ABS) positioning, which retains the measuring position when the gauge is turned off. A zero-set button lets you start measuring at any point.
Measuring Range | Accuracy | Measuring Increments | Base | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Metric | Inch | Metric | Inch | Metric | Scale Measuring Increments | Column Material | Wd. | Lg. | Batteries Included | Manufacturer Model Number | Each | |
| 0"-12" | 0 mm-300 mm | ±0.0015" | ±0.040 mm | 0.0005" | 0.01 mm | 0.1" | Steel | 4" | 6" | Yes | 3754-12/300 | 00000000 | 0000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.050 mm | 0.0005" | 0.01 mm | 0.1" | Steel | 4 3/4" | 7 3/4" | Yes | 3754-24/600 | 00000000 | 00000000 |
| Replacement Battery (1/Pkg.) | 0000000 | Pkg. | 00000 |
Electronic Height Gauges
View measurements on an LCD display to quickly confirm height before you mark and cut material. For high accuracy and precision, these height gauges use a linear scale with an encoder. Sensors in the encoder detect exact positions and convert them into electronic signals, getting rid of human error. With an SPC data output, you can connect these gauges to a computer or data processor to analyze data and monitor measurements in real time. They have zero-position memory, also known as absolute (ABS) positioning, which retains the measuring position when the scale is off. All are rated IP54 to withstand dust and splashing water.
Gauges with a magnetic base anchor to metal surfaces, so they won’t move and throw off measurements. Made of aluminum, the base is lightweight.
Gauges with a hand wheel give you smoother and finer height adjustments than sliding the scriber up and down the column.
USB adapters (sold separately) connect your gauge to your device to send data.
Wireless data transmitters (sold separately) send outputs to your computer from nearly 50 ft. away.
Wireless data connection kits (sold separately) directly send outputs to Bluetooth-enabled devices from up to 16 ft. away.
Measuring Range | Accuracy | Measuring Increments | Base | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | Metric | Inch | Metric | Inch | Metric | Column Material | Wd. | Lg. | Batteries Included | Environmental Rating | Includes | Each | |
Magnetic Base, Linear Scale, Zero-Position Memory (ABS) | |||||||||||||
| 0"-6" | 0 mm-150 mm | ±0.001" | ±0.03 mm | 0.0005" | 0.01 mm | Stainless Steel | 1 1/2" | 3 15/16" | Yes | IP54 | Carbide-Tipped Scriber | 0000000 | 000000 |
Hand Wheel, Linear Scale, Zero-Position Memory (ABS) | |||||||||||||
| 0"-12" | 0 mm-300 mm | ±0.001" | ±0.03 mm | 0.0005" | 0.01 mm | Stainless Steel | 3 15/16" | 5 7/8" | Yes | IP54 | Carbide-Tipped Scriber, Scriber Clamp | 0000000 | 000000 |
| 0"-18" | 0 mm-450 mm | ±0.002" | ±0.05 mm | 0.0005" | 0.01 mm | Stainless Steel | 4 3/4" | 7 3/16" | Yes | IP54 | Carbide-Tipped Scriber, Scriber Clamp | 0000000 | 000000 |
| 0"-24" | 0 mm-600 mm | ±0.002" | ±0.05 mm | 0.0005" | 0.01 mm | Stainless Steel | 4 3/4" | 7 3/16" | Yes | IP54 | Carbide-Tipped Scriber, Scriber Clamp | 0000000 | 000000 |
